x제품 상세 정보
| 제품 이름 | 레이저 메탄 원격 감지기 | 측정 범위 | PPM, 0–100% LEL, 0–100% Vol |
|---|---|---|---|
| 경보 | 자동 펌프 종료를 통한 메탄 임계 값 경보 | 방폭 마킹 | Ex IB IIB T4 GB |
| 펌프 속도 | 1.3 L/분 | 실행 시간 | 10 시간 연속 작동에 대한 6 시간 충전 |
| 보증 | 1 년 | ||
| 강조하다 | Zetron PTM600-L methane detector,portable laser methane detector,methane detector with 10h runtime |
||
제품 설명
Zetron PTM600-L Laser Methane Remote Detector
Long-lasting endurance, stable and reliable performance with 6-hour charging for 10-hour continuous operation.
Product Specifications
| Attribute | Value |
|---|---|
| Product Name | Laser Methane Remote Detector |
| Measuring Range | ppm, 0–100% LEL, 0–100% VOL |
| Alarm | Methane threshold alarm with automatic pump shutdown |
| Explosion-proof Marking | Ex ib IIB T4 Gb |
| Pump Rate | 1.3 L/min |
| Runtime | 6 h charging for 10 h continuous operation |
| Warranty | One year |
Product Overview
The Zetron PTM600-L is designed for highly accurate detection of methane gas, whether from buried pipeline leaks or in ambient air. It features ultra-fast response, outstanding sensitivity, and a long service life, ensuring reliable methane concentration measurement. By applying advanced wavelength-locking technology, the PTM600-L eliminates the need for routine calibration. Its compact design enables direct installation on inspection vehicles, significantly improving leak detection efficiency.
Key Features
- Smart Patrol System - Records and manages inspection data in real time
- Versatile Probes - Includes handheld and carpet probes for multiple inspection environments
- High-Flow Pump - Ensures efficient gas sampling with 1.3 L/min flow rate
- TDLAS Laser Technology - Delivers faster and more precise methane leak detection
Applications
The PTM600-L Laser Methane Detector is purpose-built for detecting methane leaks in a wide range of environments. It is widely applied in municipal underground pipeline patrols, residential and courtyard network inspections, gas stations, and long-distance transmission lines. With its 0.1-second rapid response, 1 ppm sensitivity, and vehicle-mounted or handheld flexibility, the PTM600-L ensures reliable leak detection even in complex or harsh conditions. Its rugged IP66 protection and explosion-proof design make it ideal for industries such as energy, chemical, and municipal utilities, helping safeguard infrastructure and public safety.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | PTM600-L |
| Detected Gas | Methane (CH₄) |
| Measuring Range | ppm, 0-100% LEL, 0-100% VOL |
| Alarm | Methane threshold alarm with automatic pump shutdown |
| Explosion-proof Marking | Ex ib IIB T4 Gb |
| Pump Rate | 1.3 L/min |
| Operating Temperature | -20℃ ~ 50℃ |
| Communication | Charging port, Bluetooth |
